System specification |
|
|
System type |
Gyro stability |
|
Weight |
≤330g |
|
System characteristics |
|
|
Platform type |
Triple-axial |
|
Pitch |
-100°~+40° |
|
Roll |
-45°~+45° |
|
Yaw |
360°rotation |
|
Max angular velocity |
≥100°/s |
|
Stability accuracy |
0. 1mrad(1°/2Hz)(1σ) |
|
Motor encoder accuracy |
≤0.3° |
|
Visible Light Imaging (8mm) |
|
|
Resolution and frame rate |
2560×1440 @60fps |
|
FOV |
38.3°×22. 1° |
|
Thermal IR (18mm) |
|
|
Resolution and frame rate |
640×512@60fps |
|
FOV |
24°×18. 1° |
|
Target tracking |
|
|
Tracking speed |
≥40°/s |
|
System external interface |
|
|
Control interface |
RS232 |
|
Video output |
Network |
|
Power supply |
|
|
Supply voltage |
12V~28V |
|
Power consumption |
Av.≤10W |
|
Max.≤20W |
|
|
Environmental condition |
|
|
Working temp |
-20℃~+60℃ |
|
Storage temp |
-20℃~+60℃ |
