J58TA-DF
|
J58YA-DF
|
tolerance
|
|
Optics
|
Magnification(X)
|
8
|
10
|
±5%
|
|
Objective lens diameter (mm)
|
32
|
42
|
±0.5mm
|
|
Eyepiece diameter (mm)
|
22
|
22
|
±0.5mm
|
|
Exit pupil diameter (mm)
|
4
|
4.2
|
±10%
|
|
Exit pupil distance (mm)
|
19.3
|
18.8
|
+5 to -0.5mm
|
|
Launch aperture(mm)
|
10
|
10
|
±5%
|
|
Receiving aperture(mm)
|
32
|
42
|
±0.5mm
|
|
Field of view (°)
|
6
|
4
|
±5%
|
|
1000 meters visible range (m)
|
105
|
70
|
±5%
|
|
Close focus distance (m)
|
3.5
|
7
|
±5%
|
|
Laser divergence angle (mrad)
|
3
|
3
|
±5%
|
|
Aiming accuracy (m<°)
|
target@500<0. 1
|
target@500<0. 1
|
<0. 1°
|
|
transmittance
|
>80%(NO OLED)
|
>80%(NO OLED)
|
-
|
|
center resolution
|
10 ″
|
10 ″
|
maximum value
|
|
Diopter adjustment(D)
|
+5~-5
|
+5~-5
|
-5/+L225dpt
|
|
structure
|
visual zero point mark
|
have
|
have
|
-
|
|
Binocular eyepieces with adjus
|
t Adjustable visibility on both sides
|
Adjustable visibility on both sides
|
-
|
|
Binocular distance (shaft structure) (mm)
|
Adjustable (≥58~<72)
|
Adjustable (≥58~<72)
|
±2
|
|
Eye patch segment sense
|
have
|
have
|
-
|
|
Binocular distance breaking for
|
7~ 14
|
7~ 14
|
±1
|
|
Eyepiece protective cover
|
Yes (left and right)
|
Yes (left and right)
|
-
|
|
Objective lens protective cover
|
Yes (left and right)
|
Yes (left and right)
|
-
|
|
Lanyard hole
|
Yes (both sides)
|
Yes (both sides)
|
-
|
|
Battery direction mark
|
There is a battery compartment mark
+- direction
|
There is a battery compartment mark
+- direction
|
-
|
|
Display type
|
Reflective OLED
|
Reflective OLED
|
-
|
|
Nitrogen filling
|
Double valve nitrogen pressure
|
Double valve nitrogen pressure
|
-
|
|
electronic
|
Mode button
|
have
|
have
|
|
|
switch button
|
have
|
have
|
|
|
Ranging range (m) (building)
|
10~ 1500/2000/2500
|
10~ 1500/2000/2500/3000
|
min-max
|
|
Measuring range of leaves (m)
|
≈800/≈ 1200/1400/≈ 1600
|
≈800/≈ 1200/1400/≈ 1600
|
minimum value
|
|
Deer detection range (m)
|
≈500/≈600/≈700/≈800
|
≈500/≈600/≈700/≈800
|
minimum value
|
|
Ranging accuracy (m) (buildin
|
g
|
①≤1000m±1m ②
>1000m,±(d*0.3%)
|
①≤1000m±1m ②>1000m,±(d*0.3%)
|
maximum value
|
|
Ranging response time (S (m))
|
1:＜0.3 (≤400) 2:＜0.7
（400~ 1000) 3:＜1.5
（1000~2000） 4: < 3 (3000)
|
1:＜0.3 (≤400) 2:＜0.7（400~ 1000) 3:＜1.5（1000~2000） 4: < 3 (3000)
|
maximum value
|
|
Inclination range (°)
|
±60 (adjustable to ±90)
|
±60 (adjustable to ±90)
|
minimum value
|
|
Inclination accuracy (°)
|
±1
|
±1
|
|
|
Rain and fog mode
|
None (reserve optional)
|
None (reserve optional)
|
-
|
|
final target mode
|
yes
|
yes
|
-
|
|
Yard/meter switching
|
have
|
have
|
-
|
|
Display brightness adjustment
|
none
|
none
|
-
|
|
Low battery indicator
|
There are /3 levels
|
There are /3 levels
|
-
|
|
Display auto-off(S)
|
8
|
8
|
-
|
|
Laser type (nm)
|
905(class 1 Iaser)
|
905(class 1 Iaser)
|
-
|
|
battery model
|
CR2 battery (capacity 800mAh)
|
CR2 battery (capacity 800mAh)
|
-
|
|
Power consumption (W)
|
<1.5w
|
<1.5w
|
min-max
|
|
Bluetooth
|
None (Bluetooth, azimuth, and GPS reservation can be selected)
|
None (Bluetooth, azimuth, and GPS
reservation can be selected)
|
|
|
Azimuth angle (°)
|
None (Bluetooth, azimuth, and GPS reservation can be selected)
|
None (Bluetooth, azimuth, and GPS
reservation can be selected)
|
|
|
GPS
|
None (Bluetooth, azimuth, and GPS reservation can be selected)
|
None (Bluetooth, azimuth, and GPS
reservation can be selected)
|
|
|
Function
|
M1: distance measurement + angle measurement; M2: distance
measurement + level measurement; M3: distance measurement + height measurement
|
M1: distance measurement + angle measurement; M2: distance
measurement + level measurement; M3: distance measurement + height measurement
|
|
|
Reliability
test
|
Protection level
|
IP67
|
IP67
|
|
